Specifications

• Engine

  add remove
  • Engine:
    Standard
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    39.5
  • Torque (Ft Lbs):
    29.5
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.31
  • Stroke (in):
    3.21
  • Displacement (cc):
    452
  • US Miles Per Gallon (City):
    70
  • Compression ratio:
    11.5:1
• Transmission

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    84.5
  • Width (in):
    32.8
  • Height (in):
    44.3
  • Wheelbase (in):
    56.7
  • Ground Clearance (in):
    6.7
  • Wet Weight (lbs):
    406
  • Engine Displacement to Weight (cc):
    1.18
  • Fuel Capacity (gal):
    2.9
  • Dry Weight (lbs):
    382
  • Payload Capacity (lbs):
    421
  • Payload Capacity (kgs):
    191
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    5.5
  • Rear Travel (in):
    5.9
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    120/70 R17
  • Rear Tire (Full Spec):
    160/60 R17
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
