Specifications

• Engine

  add remove
  • Engine:
    Standard
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    20.2
  • Torque (Ft Lbs):
    19.9
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.83
  • Stroke (in):
    3.38
  • Displacement (cc):
    349
  • Compression ratio:
    9.5:1
• Transmission

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    84.3
  • Width (in):
    33.3
  • Height (in):
    51.6
  • Wheelbase (in):
    55.1
  • Ground Clearance (in):
    6.7
  • Wet Weight (lbs):
    421
  • Engine Displacement to Weight (cc):
    0.83
  • Fuel Capacity (gal):
    4
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    2
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.1
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    100/90 R19 57P
  • Rear Tire (Full Spec):
    140/70 R17 66P
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    11.8
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
